List Price: CAD 264.55 CAD 145.50 -45%
The AAU-HS24 Series is a low profile strobe and horn/strobe combination that offers dependable audible and visual alarms and the lowest current available. The AU-HS24 Series is available in fixed candela options of 15/75 and 177. The AU-HS24 Series has a minimal operation current and has a minimum flash rate of 1Hz regardless of input voltage. The AU-HS24 Series is shipped with the standard 4" metal mounting plate which incorporates the popular Slide feature that allows the installer to easily test for supervision. The product also features a locking mechanism which secures the product to the bracket without any screws showing.
The AU-HS24 Series appliances are UL 464 and UL 1971 listed for use with fire protective systems and are warranted for three years from date of purchase.
• 24VDC units have field selectable candela options of 15, 30, 60, 75 & 110
• Switch selection for high or low dBA
• UL listed
CAD 45.25
The PSN-1000 series is a UL listed intelligent 10 amp notification power supply and P-Link (RS-485) repeater. The power supply connects to the P-Link bus from the control panel and is operated and supervised from the panel. The power supply may be installed 6,500 feet from the control panel.
CAD 803.80
The ZA-42 Zone Expansion adder is a simplistic means to expand the PFC-5004E into an Eight Zone Class B (Style B) or a Four Zone Class A (Style D) fire alarm control panel. In addition, the ZA-42 expands the panel to have Four Notification Circuits rated at 1.7 amps each.
CAD 173.03
• Connect the EOL Diode Resistor Assembly as required at remote locations for supervision of releasing circuit solenoids and electric actuators.
• Resistor Value – 5.1K Ohm / 5% Tolerance.
• Refer to panel installation manuals for additional details
CAD 6.59
